Application: determine the strength and deformation characteristics of the soil specimen. Perform unconsolidated-undrained shear test(UU), consolidated-unstrained shear test(CU) and
consolidated-drained shear test(CD).
Technical parameters:
1. Specimen size: О¦61.8Г—125,О¦101Г—220mm
2. Axial load:80KN
3. Lift speed range(mm/min): 003пЅћ4.800
4. Max. Stroke: 50mm
5. Max. confining pressure: 2.5MPa
6. Max. back pressure: 1MPa
7. Pore water pressure: 0-2MPa
8. Volume change range: 0-50ml
9. Min. division: 0.1ml
10. Axial displacement range: 0-30mm
