Application: It used to test shear strength of coarse grained soil which particle size is 60mm.

Specification:
1. Size of the soil sample: Dia.30cmX60cm
2. Axial loading: 1500kN
3. Max.stroke: 300mm
4. Max. Confining pressure: 3MPa
5. Max. Back pressure: 1MPa
6. Pore water pressure: 2MPa
